Gigalink RR-GV42M 6 Port PoE+ Switch, 4 PoE + 2 Uplink, 65W

Gigalink RR-GV42M 6 Port PoE Switch

The Gigalink RR-GV42M PoE switch price in BD is on this page. The RR-GV42M takes the four-port PoE+ design of the RR-GV41P and adds a second uplink, which makes cabling simpler when your camera system needs to reach both an NVR and a router or another switch.

Port layout

• Four 10/100Mbps PoE+ ports for IP cameras, access points or IP phones
• Two RJ45 uplink ports
• IEEE 802.3af/at with up to 30W per PoE port

Why two uplinks help

In a typical installation the NVR records the cameras while the router provides internet for remote viewing on your phone. With two uplinks, you connect the NVR to one and the router to the other, with no need for an extra small switch. Installers can also daisy-chain to another PoE switch for more cameras.

Built-in 65W supply

The internal 65W power supply powers the switch and every PoE device from one mains socket. That is ample for four IP cameras, including models with infrared night vision that draw more power at night.

Clean, reliable installation

Each camera needs only one network cable carrying both video and power. Store-and-forward switching checks every frame for errors to keep recordings smooth. There is nothing to configure: plug in and it works.

Backup tip

Connect the switch and NVR to a small UPS or mini online UPS, and your cameras keep recording through load-shedding since they all draw power from the switch.

Typical uses

Four-camera systems for homes, shops, restaurants, clinics and small warehouses, or small offices powering an access point and IP phones.

Buy from QASWATEC

QASWATEC sells genuine Gigalink networking products with an invoice and a 1-year warranty. Visit our Elephant Road, Dhaka showroom or order online for delivery across Bangladesh.
